Rigging screw - M3 - 30-30 - self-locking - SAILSetc
$6.00
Rigging screw - M3. Single end design, nickel plated brass, M3 thread, self locking design, 1.2 mm Ø stainless steel wire.
| Product | Thread | Body Length | Wire Length | Wire Ø | End | Adjustment | O ring (082) |
| 030-020 | M2 | 20 | 70 | 0.9 | - | 14 | 1.5 Ø |
| 030-025 | M2.5 | 25 | 70 | 1.2 | - | 15 | 1.8 Ø |
| 030-030 | M3 | 25 | 70 | 1.2 | 040-020 | 15 | 2.5 Ø |
| 030-035 | M3.5 | 30 | 95 | 1.5 | 040-025 | 22 | 3.5 Ø |
| 030-040 | M4 | 30 | 95 | 1.8 | 040-M4-HD | 23 | 3.5 Ø |
This SELF LOCKING rigging screw can be used in a NON SELF LOCKING mode by removing the O ring. Add a normal M3 nut or a Nyloc self locking nut as preferred to provide the lock nut function.
